High-precision Offline Servo Press-fit Machine TY-PT750/L

1. Robust and durable H-shaped structure with high-load-bearing slide rails. servo motor drive, precision ball screw transmission for accurate control of pressing displacement;

2. Multiple operating modes, segmented control during pressing process to meet precise assembly requirements for different products;

3. SPC management module, database management module, log management module, production traceability module, and operation permission management module;

4. High-precision pressure force sensing system with press force accuracy of ±1% (full scale);

5. Manual quick-change upper tool, optional automatic upper tool change function;

6. Integrated upper tool design is able to press multiple components, saving tool-change time and improving production efficiency;

7. Pressure curve auto-saving module and pressure curve analysis module;

8. Real-time display of pressure curve provides accurate feedback on pressing process status;

9. PVFS sampling and curve slope control function module;

10. CCD vision for the precise press-fit position by acquiring pressing coordinates;

11. Optional laser height sensing module for height and thickness detection of PCB and connector;
