Feature
1.The base is equipped with an adjustable M16mm load-bearing foot cup, with a 1.5mm thick iron plate sealing the perimeter;
2.25W speed control motor;
3.Special aluminum alloy guide rails, all stainless steel chains, and dedicated manual amplitude adjustment mechanism;
4.An independent control cabinet with a microcontroller.
5.Electrostatic spraying (computer white).
Detail Image
Specifications
|
type
|
Specifications
|
TY-C80
|
|
delivery
system
|
Work Direction
|
L→R
|
|
delivery head
|
910±20mm
|
|
|
Transfer component height
|
100mm above and below the conveyor
|
|
|
transporting velocity
|
0.5-5m/min
|
|
|
Transfer motor
|
25W speed-adjustable motor with digital display
|
|
|
Adjustment method
|
Manual AM
|
|
|
Adjust width
|
50-460mm
|
|
|
Load on rail
|
4.5Kg/m uniform distribution
|
|
|
Equipment
and venue
requirements
|
outline dimension
|
L800mm*W850mm*H910mm
|
|
weight of equipment
|
Approx.80Kg
|
|
|
Exhaust volume requirement
|
not have
|
|
|
device power supply
|
AC220V 50-60Hz
|
|
|
Total device power consumption
|
0.2KW
|
